Function
• When connect UPS with AC power. UPS automation Power On
• When battery low ups shutdown, when AC recovery UPS will automation Power On
• When Power Off UPS will bypass
Features:
• Bigger charge current Maximum 12A ，charge faster & Adjustable between 1-12A
• The output power factor can reach 1.0
• The new topology , high power density circuit is better for noise and surge protection
• Shipping cost saving with it’s perfect structure by smaller dimension
• Efficiency upto 95.5%, Higher efficiency same power with less electric bill ,
higher efficiency , same power , same backuptime with smaller battery .
• Standard & long backup are common with same PSDR&Control pcb
helps to reduce stock & easy management
• Output voltage 208V 220V 230V 240V are adjustable
• Pure sine wave output, online zero conversion time
• Wide input frequency range, adjustable from 40-70HZ
• With output short-circuit protection and overload protection
• Using LCD display screen, status parameters are clear at a glance
• RS232 communication interface is applied
• Double-sided circuit board design for higher safety and reliability
• The screen can set various of common technical parameters
• It can be equipped with power monitoring software to enable UPS network and remote monitoring
